10dB cable loss compensation TDD bidirectional amplifier Down link signal triggered TDD switching 1uS rising/falling time Low receive noise figure Output mismatch protection Isolator GaAsFET design
WLAN-BDA236
10dB cable loss compensation TDD bidirectional amplifier Down link signal triggered TDD switching 1uS rising/falling time Low receive noise figure Output mismatch protection Isolator GaAsFET design
Frequency Synthesizer for Instrument(FHSZ-4080)
4~8GHz frequency sweep generator 1Hz resolution Low phase noise Fast switching time Internal & external 10MHz reference Multi loop PLL/DDS hybrid design YIG based main oscillator 3wire serial data interface 2wire trigger handshake
Pulsed Power Amplifier(09G10-50)
9.7~10GHz frequency range 50W pulsed output power 25KHz(40uS period)/1.2% duty cycle pulsed operation 200nS pulse delay 20nS rising/falling time -167dBm/Hz output noise @ pulse off state 90° hybrid combined GaAsFET design
S-BAND LNA
Input Frequency range 2.8GHz Output Frequency range 2.8GHz
High Power Amp(AMCPA6016K)
1840 ~ 1860MHz frequency range Average output power 42dBm BW 20MHz Analog Predistortion
High Power Amp(MCPA6016 APD)
2150 ~ 2170MHz frequency range Average output power 42dBm BW 20MHz Analog Predistortion
CWPA 1100(CDMA) 100W
869 ~ 896 MHz frequency range Average output power 50dBm 100W BW 30MHz
CWPA 2100(DCS1800)
1805 ~ 1880MHz frequency range Average output power 50dBm 100W BW 75MHz
CWPA6100(WCDMA)
2110 ~ 2170MHz frequency range Average output power 50dBm 100W BW 60MHz
CWPA2200(PCS)
1860 ~ 1880MHz frequency range. Average output power 53dBm. 200W
HPAM
L-Band TDD HPA Average output power 41dBm Spurious <-60dBc TDD switching time <5us Operation Temperature -20℃ ∼ +60℃
Low Noise Amplifier(LNA.2)
1000 ~ 3000 MHz frequency range Gain : 16±1.25dB, Noise figure max. 3.5dB operating temperature -20℃~60℃ Low cost, High efficiency, Compact size Various alarm interfaces available
Low Noise Amplifier(LNA.1)
15 ~ 1300 MHz frequency range Gain : 15±1dB, 25±1dB (Alternative Function) Noise figure max. 3dB ▶ operating temperature -20℃~60℃ Low cost, High efficiency, Compact size Various alarm interfaces available
MCPA 6016
2150 ~ 2170MHz frequency range. Average output power 42dBm. ACLR@42dBm Pout : 53dB@Fc ?10MHz Operating Temperature -30 ~ 55?C
MCPA 2016
1840 ~ 1870MHz frequency range. Average output power 42dBm.
